46

Appendix B - Operation Using VT 100 Compatible Terminal

If the LCR-II is operated using a VT 100 compatible terminal (instead of the LC Lap Pad), refer to the following chart for
the terminal keystrokes that correspond to the Lap Pad keystrokes. VT 100 communication parameters that must be
observed include:

Baud Rate (9600)

Data Bits (8)

Parity (None)

Stop Bits (1)

Flow Control (None).

Operation

Lap Pad Keystroke

PC Terminal Emulation

Return to Top Level Menu

M1

Move to Next Menu Item

Move to Previous Menu Item

Select Item

ENTER

ENTER

Submit Data and Return

ENTER (after data entry)

ENTER (after data entry)

Move to Next Field

Move to Previous Field

Clear Field/Start Data Entry

Clear

Backspace

Start

Start

Stop

Stop

Print

Print

Move to Next Screen

M#
