30

Diagnostics/Factory Calibration

DIAGNOSTICS CONTINUED

PULSR FAULTS

This field displays the number of quadrature pulser faults detected during the last delivery. DISPLAY
ONLY
.

FACTORY CALIBRATION (ONLY ACCESSIBLE BY LC FACTORY PERSONNEL)

R100.0

Used by qualified personnel to calibrate the temperature probe.

R128.6

Used by qualified personnel to calibrate the temperature probe.

RAW ADC

This is the raw value being returned by the A to D converter used by the temperature probe and can be
used to assist qualified personnel in troubleshooting.

RTD SLP

The RTD Slope is displayed here. This value can assist qualified personnel in troubleshooting.

RTD OFS

The RTD Offset is displayed here. This value can assist qualified personnel in troubleshooting.

Press to advance to:

SERIAL ID

The LCR-II printed circuit board serial number is shown here.

USER KEY

This is where the owner/office password is entered or viewed. When the system is locked, the operator
will be prevented from changing field entries with the exception of GROSS and NET PRESET, PRODUCT
CODE
, PRODUCT DESCRIPTION and NO-FLOW TIMER. If the password is lost or forgotten, it can
be recovered by the factory in this screen.

LCR RESET

This is a factory-entered value that will assist qualified personnel in clearing out memory problems,
should they arise.

NOTE: A complete flow chart of the Lap Pad Menu structure appears in Appendix D.

Diagnostics - Screen 4

PULSR FAULTS

0

R 1 0 0 . 0
- 1 0 5 . 2

R A W A D C
7 9 6

R 1 2 8 . 6
2 8 8 4 . 7

R T D O F S
2 . 6 0 5

R T D S L P
0 . 0 2 4 7 5

F a c t o r y C a l i b r a t i o n - S c r e e n 1

7200015

NO

Factory Calibration - Screen 2

LCR RESET^

USER KEY

SERIAL ID
