19

Lap Pad Calibration & Set-up

STEP 6: PRODUCT CALIBRATION

Press M1 to return to the top-level menu. Press i to scroll to PRODUCT CALIBRATION.

There are four product calibrations that can be set up in the LCR-II. The products are calibrated one at a time. Press
ENTER and the cursor will move to:

#^(Product Number)

This number will correspond to one of the four product types/calibrations that can be set up in the LCR-
II. At least one calibration must be set up to allow deliveries. Press ENTER and the cursor will drop to
the bottom line. Use i to scroll between the four choices, 1 to 4. Press the ENTER key when the
desired choice is displayed.

Press and the cursor will move to:

CODE

A five character alphanumeric code can be entered here. The code will correspond to one of the
products within this product type. This code can also be entered in the DELIVERY & PRESET menu.
Press ENTER and the cursor will drop to the bottom line. Enter a code that will aid the operator in
identifying the product or one that has been specified for use by a host computer system. Press ENTER
and the cursor will move to the top line.

Press and the cursor will move to:

PRODUCT NAME

The PRODUCT NAME contains a product description (up to 18 alphanumeric characters) that will print
on the delivery ticket. NOTE: Make sure that the PRODUCT NAME matches up with the PROD
TYPE^
, #^, and CODE that are also entered on this screen. This name can also be entered in the
DELIVERY & PRESET menu. Press ENTER and the cursor will drop to the bottom line. Enter the
appropriate PRODUCT NAME. Press ENTER and the cursor will move to the top line.

Press and the cursor will move to:

PROD TYPE^

This field will scroll along with the #^(Product Number) that is shown in the first field. The product type
AMMONIA, AVIATION, DISTILLATE, GASOLINE, METHANOL, LPG, LUBE OIL and "blank" can
also be set up in the PRODUCT & SHIFT INFORMATION menu.

Press and the cursor will move to:

COMPENSATION TYPE^

Select the type of Temperature Volume Compensation to be used for this specific product number. No
deliveries are permitted if the LCR-II is configured for temperature compensation and the temperature
circuit has failed or the measured temperature is out of the specified range (see Table in Appendix A).

Product Calibration - Screen 1

PRODUCT TYPE

DISTILLATE

PRODUCT NAME
Product Name

CODE
12345

#^
1

Product Calibration - Screen 2

BASE TEMP

15.0

COMP PARAM

653

COMPENSATION TYPE

TABLE 54B
