Diagnostics/Factory Calibration

Most of the DIAGNOSTICS fields are for DISPLAY ONLY. They contain information that can be useful in troubleshooting.

DIAGNOSTIC MESSAGES^

This field allows an operator to check pending diagnostic messages. Press ENTER and the cursor will
drop to the second line of the screen. Press to scroll through the list of messages. The last message
is "END OF LIST".

SUPPLY VOLTAGE

The field shows the current supply voltage. The correct operating voltage is +9 to +28 VDC. DISPLAY
ONLY. NOTE: Voltage above +17 VDC will not indicate correctly.

Press to advance to:

SOFTWARE

The software number is shown here. This number is critical for any troubleshooting discussions with the
Liquid Controls factory service personnel. DISPLAY ONLY.

LANGUAGE

The software number designating language selection (English, Spanish, etc.) is displayed here. DISPLAY
ONLY.

TICKET

The software number designating the ticket format is displayed here. DISPLAY ONLY.

Press to advance to:

GROSS COUNT

This field displays a running total of the gross number of units for the current delivery. DISPLAY ONLY.

RATE

This field displays the actual flow rate. DISPLAY ONLY.

UNITS

This field displays the units of measure for flow total.

RATE BASE

This field displays the time base for flow rate.

Press to advance to:

DIAGNOSTICS

Diagnostics - Screen 1

SUPPLY VOLTAGE
13.5

DIAGNOSTIC MESSAGES^
TVC ACTIVE

Diagnostics - Screen 2

TICKET
ST200v1.05

LANGUAGE
SL200v1.04

SOFTWARE
SR210v1.00

Diagnostics - Screen 3

RATE BASE^

PER MINUTE

UNITS^

GALLONS

RATE
0.0

GROSS COUNT
0
