28

Lap Pad Basic Operation

PRESET DELIVERY WITH A LAP PAD CONTINUED

PRESET

The PRESET amount can be entered here. A preset of GROSS or BOTH must have been selected in
GENERAL SETUP.

REMAINING

This field displays the number of units remaining for the current delivery. DISPLAY ONLY.

UNITS^

This field displays delivery units selected during CALIBRATION: GALLONS, LITRES, CUBIC METERS,
LBS, KGS, BARRELS, and OTHER.

Press to advance to:

PRICE/UNIT

Enter value.

TAX/UNIT

Enter unit tax if applicable.

%TAX

Enter % Tax rate if applicable.

Press to advance to:

SUBTOTAL

Price per unit times quantity. DISPLAY ONLY.

TAX

Total of all taxes for delivery. DISPLAY ONLY.

TOTAL

Sum of SUBTOTAL plus TAX. DISPLAY ONLY.

Press to advance to:

AUX OUT 1^

This field activates optional outputs, e. g. pump control, additive injection, alarms, etc. Choices are
OFF, ON, ON DURING DELIVERY or MONITOR FLOWRATE. MONITOR FLOWRATE becomes
active at the beginning of each delivery. If the flowrate meets or exceeds 40 units/time, the output
deactivates. If the flowrate does not meet or exceed 40 units/time, the output remains active.

AUX OUT 2^

This field can be programmed to indicate FLOW DIRECTION or it can be programmed similar to the
AUX OUT 1^ functions of OFF, ON, or ON DURING DELIVERY.

Delivery & Preset - Screen 6

TOTAL
0.000

TAX
0.000

SUBTOTAL
0.000

Delivery & Preset - Screen 7

AUX OUT 2^
FLOW DIRECTION

AUX OUT 1^
ON DURING DELIVERY

Delivery & Preset - Screen 5

PRICE/UNIT
0.000

%TAX
0.000

TAX/UNIT
0.000
