PARTS INCLUDED
OR
*For Patriot II quantity is doubled.
Additionally, 40’ of Master/Slave Actuator cable provided with the Patriot II
Placards (Two supplied) should be visible from inside and outside of gate.
NOTE: +12 Volt maintenance free lead acid, Gel or AGM battery recommended.
33-amp hour minimum required. (Not Included)
* 2” X 2” X 17”
Hinge Mount Tube
Solar Panel with Bracket
and hardware
*5- ½” washers
*1- ½” Locknuts
2- Placards * ½” X 4 ½” Bolt
*Manual Release Pin
And Clip
* Gate Bracket
WARNING
A Moving Gate Has The Potential Of Inflicting Serious Injury Or Death
Persons are to keep clear! The gate is able to be moved without prior warning.
Do not let children operate the gate or play in the gate area.
Persons are to operate the gate only when the gate area is in sight and free of people and obstructions.
Battery
Charger
Solar Panel
One 4-Button visor
mount and two
4-Button key fob
remote/transmitters
41 ½”
Cabinet with
Control Board
and Receiver
18”
8 ½”
18”
*Actuator Arm with 8 foot of Cable
Secondary
Entrapment Siren
+12vdc
Sun Guard
Charge
Controller
