Controlled Products Systems Group 9150-080 - Manual (Page 5)

9150-065-S-9-11 3
SECTION 5 - WIRING 31
31
32
33
34
5.1 Main Terminal Description
5.2 Control Wiring for Single/Primary Operator
5.3 Auxiliary Device Wiring
5.4 Bi-Parting Gates Wiring - Dual Gate Operators
SECTION 8 - MAINTENANCE AND TROUBLESHOOTING 41
8.1 Maintenance
8.2 Troubleshooting
8.3 Accessory Items
Model 9150 Wiring Diagrams
41
42-43
44
45-52
SECTION 7 - OPTIONAL CONVENIENCE OPEN ADJUSTMENTS 39
7.1 Circuit Board (2340) Setup
7.2 DC System Description
7.3 DIP-Switch Settings
39
40
40
SECTION 6 - OPERATING INSTRUCTIONS 35
6.1 AC Power and Reset Switch
6.2 Shutdown Conditions
Soft Shutdown
Hard Shutdown
6.3 Manual Gate Operation
Fail-Safe Manual Release System
Fail-Secure Manual Release System
Emergency Vehicle Access Conditions
37-38
35
36-37
SECTION 4 - ENTRAPMENT AND SAFETY PROTECTION 27
4.1 UL 325 Terminal Description
4.2 Secondary Entrapment Protection Device Locations
4.3 Loop Detector Wiring
27
28-29
30
TABLE OF CONTENTS
