4 bi-parting gates wiring - dual gate operators, Secondar y operator, Primar y operator – Controlled Products Systems Group 9150-080 User Manual
Page 36: Secondary entrapment protection devices, Interconnection cable, Loop detectors 3-wire receiver, Jumper wire, For bi-parting gates
9150-065-S-9-11
34
ON
EXIT
LOOP
KEY SWITCH
4602
SW1
NC
NO
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
KEY SWITCH
4602
NC
NO
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
3
2
1
Open Photo
Close Photo
Open Edge
Close Edge
Common
3
2
1
Open Photo
Close Photo
Open Edge
Close Edge
Common
UL 325
Terminal
UL 325
Terminal
Secondary
Operator
Primary
Operator
To Close Photo #2
To Close Photo #2
To Close Photo #2
To Open Edge #3
To Open Edge #3
To
Common #5
To
Common #5
To Open Photo #1
To Open Photo #1
Fence
Gate
Opening Non-Contact Sensor
Closing Non-Contact Sensor
Opening Contact Sensor
Opening Contact Sensor
Opening Non-Contact Sensor
Fence
Gate
Convenience Open Note: The gray wire is needed when using the
convenience open in the manual mode (See page 40 for wiring
information about “Wiring dual operators in manual mode”).
5.4 Bi-Parting Gates Wiring - Dual Gate Operators
Secondary Entrapment Protection Devices
for Bi-Parting Gates
•
Separate power source for
photo sensors (See page 27).
Interconnection Cable
Sold separately from DoorKing.
6 wires used (8 - 18 AWG wires total).
Reverse loop lead-in
wires are wired in series.
When using Dual
Channel plug-in
loop detector.
Connect #4 to #10:
fully opens gates.
SW 2, switch 1
must be OFF.
Plug into Primary Operator Exit Loop Port
Dual Channel
9409
Automatic
Exit Loop
Reverse
Loop
Reverse
Loop
KEY SW
KEY SW
W
Secondar
y Operator
Yellow
24 Volt
Relay
Com
Purple
Brown
Yellow
Purple
Brown
Orange
Jumper Wire
Orange
Green to
primary
operator
chassis
ground.
Green to
secondary
operator
chassis
ground.
Red to Close Photo #2
Blue
Blue
Gray
Gray
Loop Lead-In Wires
Red to Close Photo #2
N.O.
Com
Loop Detectors
3-Wire Receiver
(Fully Opens Gates)
Jumper Wire
250 mamp. max.
4-wire receiver wiring,
see page 31.
ON
1
2
345678
SW 2
1
2
3
4
5
1
2
3
4
5
EY SWI
EY SW
WI
Primar
y Operator
•
Requires AC power to each operator.
•
Both operator DIP-switches must to be set.
•
Connect all control devices, auxiliary devices
and loops to the primary operator only.
Filler Post if necessary (See page 8 for more information).
Filler Post if necessary (See page 8 for more information).
