Key release – Controlled Products Systems Group 9150-080 User Manual
Page 40
9150-065-S-9-11
38
Key Release
Emergency Vehicle Access Conditions
Fail-Secure Manual Release System (Owner Installed)
Solenoid lock does NOT allow the clutch plate to rotate when:
•
The AC power is on but the operator is not cycling.
•
The AC power is turned off.
•
AC power failure.
1. During normal AC powered operation, emergency vehicles access the gate by a separate emergency access
device individually installed and wired to your gate system. The type of devices that can be used in your commu-
nity depends on your city codes. These devices may include (but are not limited to) Fire Department lock boxes,
Click-2-Enter radio receivers, strobe light sensors, siren sensors, etc.
2. In the event of an AC power failure, the emergency vehicle access device will not function because the gate
operator is un-powered. “Fail-Safe” or “Fail-Secure” release systems for the 9150 allow the gate to be manually
operated during AC power failure. ONLY the “Fail-Safe” release system allows the gate to be manually operated
without unlocking the operator first and has been designed that way to allow emergency personnel to immediately
manually operate the gate from either side under emergency situations.
This automatic vehicular gate system is designed to allow access to emergency vehicles under different operating conditions.
Solenoid
Lock
Clutch Plate
Clutch Plate
Operator
Housing
Solenoid lock automatically retracts and allows clutch
plate to rotate ONLY during normal gate cycling.
Turning key 1/2 turn
retracts solenoid lock
and allows clutch plate
to rotate for manual
operation with or
without AC power.
ON
12
3
4
5
6 7 8
SW 2
W
ARNI
NG
MO
VI
NG
GAT
E CAN
CAU
SE
Ope
rate
ga
te o
nly
w
he
n ga
te a
rea
is i
n s
ight
and
fre
e of
peopl
e a
nd
obst
ruct
ions
.
Do
not
allow
chi
ldr
en
to
pla
y in
gat
e a
rea
or
op
era
te ga
te.
Do
not
sta
nd
in
ga
te pa
th
or
wal
k thr
ough
path
w
hile
ga
te is
m
ovi
ng.
Read
ow
ne
r’s m
anua
l and
safe
ty inst
ruc
tions
.
SER
IOU
S IN
JU
RY
OR
DEA
TH
CLA
SS
CER
TIF
IED
TO
CA
N/C
SA
C2
2.2
NO
. 2
47
CO
NF
OR
MS
TO
AN
SI/U
L-3
25
VEH
IC
UL
AR
GAT
E O
PER
AT
OR
HP
533
82
MO
DE
L
SER
IAL
VO
LTS
PHA
SE
AMP
S
60 H
z
MA
X G
ATE
LO
AD
Doo
rKi
ng,
Inc
., I
ngle
wo
od,
CA
This manual release system (Installed 2600-865 Fail-Secure Manual Release Kit) allows the gate to be manually
operated ONLY after unlocking the gate operator. Power outages or turning power off WILL NOT allow gate to be
manually operated without physically unlocking the gate operator with the key first. This option is typically used in Class
III and Class IV applications. The gate operator “Fails” (Loss of AC power) in a “Secure” (Manually in-operable) condition.
SW 2, switch 4 must be ON.
Important:
solenoid lock
MUST be in position shown.
