IMPORTANT INFORMATION FOR OWNER
Standard Control Box
Shut-Off ALL Power
Shut-Off ALL Power
Shut-Off Alarm
Shut-Off Alarm
Deluxe Control Box
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
1
7 6
5 4
3 2
4302
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
4302
OFF
ON
Shut-Off ALL Power to Operator OR Shut-Off Alarm
Push button to SHUT-OFF alarm.
Turn OFF AC power switch
AND carefully disconnect battery
plug from circuit board to
shut-off ALL power to operator.
Turn OFF AC power switch
AND carefully disconnect battery
plug from circuit board to
shut-off ALL power to operator.
ALWAYS inspect the gate, gate hardware
and any obstructions along the gate’s
path that could have activated the alarm
BEFORE pressing the reset button and
putting the gate back into service. If the
gate is malfunctioning, DO NOT put it
back into service until the problem can
be corrected.
Push button to SHUT-OFF alarm.
ALWAYS inspect the gate, gate hardware
and any obstructions along the gate’s
path that could have activated the alarm
BEFORE pressing the reset button and
putting the gate back into service. If the
gate is malfunctioning, DO NOT put it
back into service until the problem can
be corrected.
