Page 12
4302-065-F-1-13
10
Brown Wire
Blue Wire
Orange Wire
Red Wire
Yellow Wire
Green Wire
Green/Yellow Wire
Not Used
1
7
8
6
5
4
3
2
1.2 Wiring Operators to 4302 Circuit Board
1
7
6
5
4
3
2
1
2
3
4
5
6
7 8
9 10 11 12 13 14 15 16 17 18 19 20
Primary or Secondary
Operator Cable Terminal
Primar
y Operator Cable
1
7
6
5
4
3
2
Secondary Operator ONLY
Primary Operator ONLY
Secondar
y Operator Cable
(Inter
connection cable)
Operator Terminal Note: The 8-pin
terminals can be unplugged from
circuit board for easy wire connections.
6400 Dual Operator Wiring ONLY!
1
7
8
6
5
4
3
2
Blue wire
Brown wire
Orange wire
Red wire
Yellow wire
Green wire
Green/Yellow wire
Not Used
SECONDARY
1
7
8
6
5
4
3
2
Brown wire
Blue wire
Orange wire
Red wire
Yellow wire
Green wire
Green/Yellow wire
Not Used
PRIMARY
6400 Primary
operator wiring
6400 Secondary
operator wiring
Secondary operator motor wires MUST
be reversed from the primary operator.
