5
Section 1 Specifications
Specifications are subject to change without notice.
Enclosure rating
PHOSPHAX sc: IP55
PHOSPHAX indoor sc: IP54
Enclosure material ASA/PC UV-resistant
Measuring method 2-beam photometer (yellow method)
Measuring range
0.05 to 15 mg/L PO
4
–P
1 to 50 mg/L PO
4
–P
Detection limit
0.05 mg/L, with standard solution: (0.05 to 15 mg/L PO
4
–P Measuring Range)
1.00 mg/L, with standard solution (1 to 50 mg/L PO
4
–P Measuring Range)
Measuring accuracy
(with standard solution) 2 % of the measured value + 0.05 mg/L (0.05 to 15 mg/L PO
4
–P Measuring Range)
2 % of the measured value + 1.0 mg/L (1 to 50 mg/L PO
4
–P Measuring Range)
Repeatability
(with standard solution) 2 % of the measured value + 0.05 mg/L (0.05 to 15 mg/L PO
4
–P Measuring Range)
2 % of the measured value + 1.0 mg/L (1 to 50 mg/L PO
4
–P Measuring Range)
Response time (90 %) < 5 minutes
Adjustable measuring interval 5 to 120 minutes
Power supply
Power supply with power cable, using the sc1000 controller only
(analyzer, Filter Probe sc, and drain tubing: 115 V versions or 230 V versions)
Data transmission Data transmission with data cable on the sc1000 controller
Electrical power consumption 500 VA
Electrical fuse protection
Via sc1000 controller
Maximum of 2 analysis instruments for each sc1000.
Outputs
Relay, current outputs, network interface via sc1000 controller. Refer to the sc1000
manual for detailed specifications for analog, relay, and digital outputs.
Operating temperature
PHOSPHAX sc: –20 to 45 °C (–4 to 113 °F); 95 % relative humidity,
non-condensing
PHOSPHAX indoor sc: 5 to 40 °C (41 to 104 °F); 95 % relative humidity,
non-condensing
Storage temperature –20 to 60 °C (–4 to 140 °F); 95 % relative humidity, non-condensing
Sample temperature +4 to +45 °C (39 to 113 °F)
Sample pressure With continuous sample preparation –30 mbar to +50 mbar at overflow vessel
Sample flow Range: 1.0–20.0 L/h
Sample quality Ultra filtrated or comparable
Sample level Level of liquid in basin with filtration probe must be below analyzer
Permissible pH value of the sample 5 to 9
Permissible chlorid range  1000 mg/L Cl –
Dimensions ( Figure 1 on page 6 ,
Figure 2 on page 7 )
PHOSPHAX sc: (W × H × D) 540 Ч 720 Ч 390 mm (21.25 Ч 28.35 Ч 15.35 in.)
PHOSPHAX indoor sc: (W × H × D) 540 Ч 720 Ч 370 mm (21,25 Ч 28,35 Ч 14.5 in.)
Data and power cable lengths 2 m (80 in.) (from edge of enclosure)
Weight
PHOSPHAX sc: Approximately 31 kg, without Filter Probe sc and without
chemicals
PHOSPHAX indoor sc: Approximately 29 kg, without Filter Probe sc and without
chemicals
