24

Installation

3.5

Electrical installation

DANGER
High voltage wiring connections are present under the
protective cover. The protective cover must remain in place
unless a qualified installation technician is installing wiring for
the Filter Probe sc or the heated drain.

See

Figure 14

for protective cover removal.

Figure 13 Sealing plug types

1

Sealing plug type 1

2

Sealing plug type 2

3

Sealing plug type 3

Figure 14 Remove the protective covers

1

Protective cover for AC mains circuits (Back view)

2

Bottom protective cover for main PCB
