101
Fieldbus
11.1 Modbus register information
Table 8 Sensor modbus registers
Tag Name Register #
Data
Type
Length R/W
Discrete
Range Min/Max
Range
Description
MEASURE VALUE 1 40001 Float 2 R
actual measurement value from
channel one
LOCATION 1 40005 String 8 R/W
Name of LOCATION 1 (see menu
system)
MEAS. 40013 Float 2 R
0/99999.9
measuring value ; photometer data
MEAS. ZERO 40015 Float 2 R
0/99999.9
measuring zero; photometer data
OFFSET MEAS. 40017 Float 2 R
0/99999.9
offset measuring; photometer data
REF 40019 Float 2 R
0/99999.9
reference value; photometer data
REF ZERO 40021 Float 2 R
0/99999.9
reference zero; photometer data
OFFSET REF 40023 Float 2 R
0/99999.9
offset reference; photometer data
AMPLIFY MEAS. 40025 Integer 1 R -100/100
amplification of measurement
channel
AMPLIFY REF 40026 Integer 1 R -100/100 amplification of reference channel
COOLING 40027
Unsigned
Integer
1 R 0/100 percentage of cooling fan power
HEATING 40028
Unsigned
Integer
1 R 0/1
status off heating for sample tube;
0=OFF, 1=ON
HUMIDITY PROBE 40029
Unsigned
Integer
1 R 0/100 humitity filtration probe in percent
ENCLOSURE
TEMP
40030 Float 2 R 0/99.9 the temperature inside the analyzer
ACTUAL VALUE 40032 Float 2 R
actual measurement value from
channel one
LOCATION 2 40034 String 8 R/W
location for the measuring channel
two where the sample is coming
from
CONTENT 40042
Unsigned
Integer
1 R 0/65535
the entry is for the device driver
file;shows the version
REMAINING TIME 40043
Unsigned
Integer
1 R 0/65535
remaining time of the current
process
CUVETTE TEMP. 40044 Float 2 R 0/99.99 actual cuvette temperature
PO4-P VALUE 1 40046 Float 2 R
measurement value for channel one
as PO4-P
PO4-P VALUE 2 40048 Float 2 R
measurement value for channel two
as PO4-P
PO4 VALUE 1 40050 Float 2 R
measurement value for channel one
as PO4
PO4 VALUE 2 40052 Float 2 R
measurement value for channel two
as PO4
P2O5 VALUE 1 40054 Float 2 R
measurement value for channel one
as P2O5
