104
Fieldbus
HUMIDITY ANALY 40127
Unsigned
Integer
1 R 0/100 humidity analyzer in percent
FIELDBUS 40128
Unsigned
Integer
1 R/W 0/2
triggers a measurement serie in
START BY BUS mode (see Start by
bus)
START BY BUS 40129
Unsigned
Integer
1 R/W 0/1
sets the analyzer to START BY BUS
mode ( see Start by bus)
EXTINCTION 2 40130 Float 2 R
-9.99999/
9.99999
the curent extinction from the
measurement channel two
PROCESS STATE 40132
Unsigned
Integer
1 R
0/1/2/3/4/
5/6/7/8/9/
10/11/12/
13/14/15/
16
the process/state of the analyzer,
coded as enum list; enum value
0=service mode, enum value
1=measuring 1..., interval,
initialisation, serv.in proc., cleaning,
warm up phase, measuring 2...,
prepump reag., prepump clean.,
prepump probe, flushing, start by
bus, calibrate, test procedure,
prepump.sample, enum value
16=validation
NUMBER OF
MEAS.
40133
Unsigned
Integer
1 R/W 1/100
Number of measurements in a
START BY BUS measurement
series (see Start by bus)
AVERAGE 40134
Unsigned
Integer
1 R/W ?
The number of measurement values
that result in an average value in a
START BY BUS measurement
series.
NO.OF VALUES
CH1
40135
Unsigned
Integer
1 R/W 0/100
2 channel mode: how often is
channel 1 measured before
switching to channel 2
NO.OF VALUES
CH2
40136
Unsigned
Integer
1 R/W 0/100
2 channel mode: how often is
channel 2 measured before
switching to channel 1
DISCHARGE VAL1 40137
Unsigned
Integer
1 R/W 0/3
number of discharged values when
switching from channel 1 to channel
2
DISCHARGE VAL2 40138
Unsigned
Integer
1 R/W 0/3
number of discharged values when
switching from channel 2 to channel
1
DISCHARGE BUS 40140
Unsigned
Integer
1 R/W 2/10
discharge values at the beginning of
a START BY BUS series
SENSOR NAME 40143 String 8 R User-assigned name for a sensor
REAG. WARNING 40151
Unsigned
Integer
1 R/W 0/1
warning if the level of reagent is low;
0=OFF, 1=ON
WARNING 40152
Unsigned
Integer
1 R/W
20/15/10/
5
Reagent warning level in percent
REAGENT LEVEL 40155
Unsigned
Integer
1 R 0/100 the level of reagent in percent
Table 8 Sensor modbus registers
Tag Name Register #
Data
Type
Length R/W
Discrete
Range Min/Max
Range
Description
