35
Section 5
Operation
The PHOSPHAX sc can only be operated with an sc1000
controller. Refer to the sc1000 user manual for more information.
An LED on the door (works with door open and closed) indicates
the current operating state. Refer to the sc1000 User Manual and
5.1 Sensor diagnostics menu
SELECT PHOSPHAX sc (if more than one sensor or analyzer is attached)
PHOSPHAX sc
ERROR LIST
Displays all errors currently present in the sensor
WARNING LIST
Displays all warnings currently present in the sensor
5.2 Sensor setup menu
SELECT PHOSPHAX sc (if more than one sensor or analyzer is attached)
CALIBRATION
CORR. FACTOR
Displays the locations and correction factors
LOCATION1
Displays location1 from CONFIGURE
GAIN CORR
sets correction factor for channel 1
LOCATION2
On 2-channel version
GAIN CORR
On 2-channel version
INTRINS. COLOR
Displays the zero extinction
EXT. FACTOR
Displays the internal device factor
OFFSET
can be used to slightly correct measurements which are close to Zero
DEFAULT SETUP
Resets the user-editable options to their factory-defaults
CONFIGURE
LOCATION 1
Settings for location 1
EDIT NAME
Enter the name for the measuring location as required.
SET PARAMETER
Output can be set as phosphate or phosphate-phosphor.
SELECT UNITS
Output in mg/lL or ppm.
QUANTITY CH 1
Number of measurements in succession ( = measurements on channel 1 +
DISCHARGE VAL 1 channel 1). Available with the 2-channel version.
DISCHARGE VAL 1
Number of discarded values after switching from channel 1 to channel 2. Available with the
2-channel version.
LOCATION 2
Settings for location 2
EDIT NAME
Enter the name for the measuring location as required (on 2-channel version).
SET PARAMETER
Output can be set as phosphate or phosphate-phosphor (on 2-channel version).
SELECT UNITS
Output in mg/l or ppm (on 2-channel version).
QUANTITY CH 2
Number of measurements in succession ( = measurements on channel 2 +
DISCHARGE VAL 2 channel 2). Available with the 2-channel version.
DISCHARGE VAL 2
Number of discarded values after switching from channel 2 to channel 1. Available with the
2-channel version.
