Operating structure
Typ 8750
TAVEL.ACCU
STROKE.CHECK
HUB
LIMIT
NEXT.M
HISTORY
CYCLE.COUNTER LIMIT
NEXT.M
HISTORY
20.0 mm
1000000 cm
1000000
TEMP.CHECK CURRENT
MAX
MIN
LIMIT
1000000
TEMP.MAX
TEMP.MIN
60.0 °C
0.0 °C
HISTORY TEMP.MAX
TEMP.MAX
Fig. 45: Operating structure FMR - 20
STROKE.CHECK MAX
MIN
LIMIT
HISTORY
POS.MONITOR DEADBAND
COMP.TIME
HISTORY
PV.MONITOR
ZERO.TOL
MAX.TOL
0.5 %
0.5 %
ZERO
MAX
2.0 %
10.0 sec
DEADBAND
COMP.TIME
HISTORY
2.0 %
10.0 sec
Fig. 46: Operating structure FMR - 21
