Operating structure
Typ 8750
SECURITY
PV-SCALE PVmin 0.0
PVmax 100.0
K-Factor 21)
P.CO-INIT
0.0 l/s
VALUE
TEACH-IN
Valve closing TEACH-IN
Teach-in at
work
-> filling VOLUME
SP-INPUT internal
external
SP-SCALE 22) SPmin 0.0
SPmax 100.0
0.0 l/s
100.0 l/s
100.0 l/s
1.0
Fig. 33: Operating structure FMR - 8
22)
Only for frequency signal type (F.CONTROL → SETUP →
PV-INPUT → Frequency)
23)
Only for external set-point value default (P.CONTROL → SETUP
→ SP-INPUT → external)
SECURITY
BINARY.IN
P.CO-INIT bumpless
standard
zeroinit
VALVE KV.FACT
KV.USER
Access Code CODE
MAIN
MANU/AUTO
ADDFUNCT
X.TUNE
P.Q‘LIN 1)
P.TUNE 1)
0000
SAFEPOS Safepos 0 %
SIG.ERROR 23) SP/CMD Input Error off
Error on
SAFEPOS SafePos off
SafePos on
PV Input
Fig. 34: Operating structure FMR - 9
24)
Only for signal type 4-20 mA and Pt 100
english
