12
Technical data
Typ 8750
Temperature range
control medium 0 – +50 °C
Pressure range
control medium
5.5 – 7 bar (DN 15 – DN 65)
5 – 6 bar (DN 80 – DN 100)
Intrinsic air consumption 0 l/min
Connections plug-in hose connector 6 mm / 1/4”
threaded connection G 1/8
Flow media air and gases
steam on request
Temperature range
Media
0 – +80 °C
Pressure range
Media
0 – 16 bar
Connections flange acc. to DIN EN 1092-1, ANSI,
JIS
Pressure measurement
range of sensor
0 – 6/10 or 16 bar
depending on the pressure range of
media others available on request
Measurement section acc. to DIN EN 60534-2-3
Orifices DN 15 - DN 100
Sensor connections threaded connection G 1/2
7.7. electrical data
Connections
Operating voltage circular plug-in connector M12 x 1, 4-pole
External signals circular plug-in connector M12 x 1, 8-pole
circular plug-in connector M8 x 1, 8-pole
Operating voltage 24 V DC
- maximum residual ripple 10 %
Power consumption < 5 W
Set-point value default 0/4 – 20 mA or
0 – 5/10 V
field bus as option
Display multifunction display
User interface 4 function keys
english
