DeviceNet start-up
Typ 8750
name
description of the input data
attributes
attribute
address class,
instance,
attribute; data
type, length
ERR
Error
Indicates the number of the process
value (output) which was not written.
The value is retained until it is deleted
with "1" by acyclically writing the
"Error" attribute (access via Explicit
Message – Set Attribute Single).
HEX
0X14 INP
0X15 SP
100, 1, 1;
USINT, 1 byte
P1
Pressure before the valve in bar
120, 1, 7;
INT, 2 byte
P2
Pressure after the valve in bar
120, 1, 8;
INT, 2 byte
MTMP
Medium temperature in °C
120, 1, 9;
INT, 2 byte
PCONact P.CONTROL active
120, 1, 10;
USINT, 1 byte
Tab. 27: Input data attributes; DeviceNet
14.2.2. static output assemblies
name
address of data
attribute of the
assemblies for
read access. class,
instance, attributes
format of the data
attribute
INP
(factory setting)
4, 21, 3
Byte 0: INP low
Byte 1: INP high
SP
4, 22, 3
Byte 0: SP low
Byte 1: SP high
MTMP
4, 23, 3
Byte 0: MTMP low
Byte 1: MTMP high
SP+MTMP
4, 24, 3
Byte 0: SP low
Byte 1: SP high
Byte 2: MTMP low
Byte 3: MTMP high
MTMP+SP+
ERR+PCON
4, 25, 3
Byte 0: MTMP low
Byte 1: MTMP high
Byte 2: SP low
Byte 3: SP high
Byte 4: ERR
Byte 5: PCON
active
Tab. 28: Static Output Assemblies, DeviceNet
The addresses indicated in “Tab. 28” can be used as a path
statement for the Consumed Connection Path attribute of an I/O
connection.
