Additional FMR functions
Typ 8750
CAL.USER - settings:
calibr. POS calibration of the position actual value
POS. pMIN Set the minimum position of the valve
POS. pMAX Set the maximum position of the valve
CAL.FMR calibration of the flow controller
CAL.PLIM Measurement range of the pressure sensor
CAL.P1 Calibration of pressure sensor 1
CAL.P2 Calibration of pressure sensor 2
CAL.P1‘P2 P1-P2 comparison increase in accuracy
CAL.TLIM
Measurement range of the temperature
transmitter
CAL.TEMP Calibrating the temperature transmitter
calibr. SP calibrating the process set-point value
SP 4mA 0 Minimum value of the input signal
SP 20mA 0 Maximum value of the input signal
calibr. PV calibrating the process actual value
for input signal 4 - 20 mA:
PV 4mA 0 Minimum value of the input signal
PV 20mA 0 Maximum value of the input signal
for input signal Pt 100:
0000 Temperature
copyFACT->USER reset to factory settings
Tab. 23: CAL.USER settings
12.3. OUTPUT - configuration of the
analog output
The analog output can send feedback regarding the current position
(POS) or the set-point value (CMD), the process actual value (PV),
the process set-point value (SP), the pressure at the input (P1), the
pressure at the output (P2) or the medium temperature (MTMP) to
the control center.
→
Add the auxiliary function OUTPUT to the main menu using the
configuration menu ( ADDFUNCTION).
→
Create the settings for the flow controller under OUT ANALOG.
