20
Electrical installation
Typ 8750
10. elecTrical insTallaTion
Danger!
risk of electric shock.
▶ Before reaching into the device, switch off the power supply and
secure to prevent reactivation.
▶ Observe applicable accident prevention and safety regulations
for electrical equipment.
Warning!
risk of injury from improper installation.
▶ Installation must only be carried out by authorized technicians and
with the appropriate tools!
risk of injury from unintentional activation of the system and
uncontrolled restart.
▶ Secure system against unintentional activation.
▶ Following assembly, ensure a controlled restart.
10.1. electrical installation, 24 V dc with
circular plug-in connector (multi-pole
variant)
signal values
Operating voltage
24 V DC
Set-point value (process controller) 0 – 20 mA; 4 – 20 mA
0 – 5 V; 0 – 10 V
Actual value 4 – 20 mA
procedure:
→
Connect the process controller according to the following tables.
When the operating voltage is applied, the process controller is
operating.
→
Now enter the required basic settings and actuate automatic
adjustment of the process controller, as described in Chapter
“11. Start-up 24 V DC”, page 25.
