Functions
Function occupied
Before a pallet is let into the function the previous flow must be finished, the
arm to be in right position and downstream receiver be ready to receive.
Example: Previous flow was straight. Pallet enters on Satellite to be
merged. Stop A2 block the flow, then wait until B3 and B4 do not detect any
pallets. When downstream Highway is ready to receive, then pallet on Sat-
ellite is released by stop A2.
Sensors
The primary function of In position sensors (B1, B2) is to detect pallet
placed in specific position. Additionally the sensors are placed in the way
they can actuate stop (open/blocking) before pallet gets into contact with
the stop up to conveyor speed 10 m/min. (if the speed is higher, an addi-
tional sensor placed upstream is needed in order to have time to actuate
before the pallet reach the stop).
