FlexLink XK Функциональные модули Руководство пользователя - Manual (Page 17)

Technical specification
Create
d
by EBCCW
0
0
:06
9 5114899
2.2 Ordering information
XKUT 45 D, XKUT 45 M, XKUT 45 C, XKUT 90 D, XKUT 90 M
and XKUT 90 C.
Configuration example
One of the six above mentioned modules has to be chosen first. Then the
questions in the configurator have to be answered.
Example of configurator string: 250x225-Left-S-2-RF
*For module XKUT 90 C the number of photoeyes will be 3, for all other
modules it will be 2.
The choice sensor "Yes" includes sensors and brackets for indicating:
• Palette in stop position.
The choice sensor "No" includes:
• Sensor bracket for palette in stop position.
Sensors and brackets that always are included:
• If palette stop is actuated or not.
• Position of arm (in diverter and combined divert/merge modules).
Question Choices Description code
Type of pallet
200x150
250x225
300x300 200x150
250x225
300x300
Right/Left
Right
Left Right
Left
Sensors
Yes
No S
N
Photoeyes
Yes
No 2 or 3*
N
RFID
Yes
No RF
N
