Functions

Create

by EBCCW

:06

5114899

Function occupied

Before a pallet is let into the function the previous flow must be finished, the
arm to be in right position and downstream receiver be ready to receive.
Example: Previous flow was on satellite. Pallet enters on highway to go
straight. Stop A1 block the flow, then wait until B2 and B3 do not detect any
pallets. Thereafter diverter change arm position. When downstream High-
way is ready to receive, then pallet on highway is released by stop A1.

Diverter arm

The position of the diverter arm A2 is indicated by sensors B6 and B7.

Stop position

The position of the stop A1 is indicated by sensors B4 and B5.

Sensors

The primary function of In position sensor (B1) is to detect pallet placed in
specific position. Additionally the sensor is placed in the way it can actuate
stop (open/blocking) before pallet gets into contact with the stop up to con-
veyor speed 10 m/min. (if the speed is higher, an additional sensor placed
upstream is needed in order to have time to actuate before the pallet reach
the stop).

RFID

The RFID head can be used to read/write RFID tag data on pallet. The data
can be used to take flow decisions at crossings, for example at stop A1.
The RFID head shall be mounted outside the module, before the stop A1.
