Configuration
• Custom: Createacustom OSD message. Enter thecustom OSD text under
Custom OSD.
Device Name
Channel ID
Channel Name
Time
Custom
3. Enter the desired Row and Column for enabled OSD messages. Text on
row 0 is shown at the top of the screen, and moves down as the row
number increases. Text on column 0 is shown on the left side of the
screen, and moves right as the column number increases.
Column 0 Column # increases
Row 0
Row #
increases
4. Click OK to update the camera OSD.
6.7.6 Microphone
Configuration
3. Un-check Enable NTP and click Apply at the bottom of the screen.
4. If your region observes daylight savings time, check Adjust clock for
daylight saving changes.
• Under Start and End, select the start and end times for daylight savings.
5. Click Set Manually, and use the on-screen calendar to set the time and
date.
6. Click Apply. The camera updates to the newly entered time.
6.7.5 OSD
The OSD page allows you to configure the camera’s on-screen display text.
To configure the camera OSD:
1. Click Device Configuration>OSD.
2. Check the following options to enable OSD text:
• Device Name: Display the Device Name.
• Channel ID: Show the channel ID number.
• Channel Name: Show the name of the channel set in the Camera menu.
• Time: Show the date and time on the OSD. Select the desired date and
time format under Time Format.
