ETV System Server Software - User’s Guide Page 86
Time in Queue Rule
The Time in Queue rule tracks how long a customer spends within a defined region in the cameras field of view. The time
will be tracked from the moment the customer enters the region until they exit the region in any direction. Alarms can be
configured to go off if a person remains in the region for more than a preset time. This works well for regions with a
defined queue area.
General Tab
Name
Display Option
The rule name is used to easily identify the rule in the settings, live and alarms
windows. When building Analytics on an Enterprise level, consider Rule Naming
conventions to simplify searching and reporting on the data.
Select when the rule should be displayed in the live viewer. Show Rule will always
display the rule, Not Show Rule will never display the rule, Show Rule When Alarmed
will only show the rule while the alarm is triggered.
Database Insert Frequency
The number of seconds between database entries. When a database insert is
performed the on-screen count restarts.
Description Enter a description for this Rule.
Check this box to allow data from this rule to sync to a central database. If this box
is not checked, this rule will not sync to a central database. This allows for rules that
Allow Data from... will be used in centralized reporting to sync to a central location, while rules that are
not needed for centralized reporting can stay local to the DVR and not use bandwidth
/ resources on the central system.
Region Settings Tab
Add
Click the Add button and then click to draw the
corners of the region. Click on the original point to
complete the region.
Edit
Click the Edit button and then click and drag the
corners of the region.
Clear Click Clear to remove all boundaries from the image.
Freeze
Video
Click the Freeze Video button to pause the live video.
Click the button again to display live video.
