ETV System Server Software - User’s Guide Page 79
People Counting Single Tripwire
The People Counting Single Tripwire Rule counts the
number of people entering and/or exiting an area
based on a tripwire line drawn across the field of view
of the camera. A single tripwire allows for accurate
counting of pedestrian traffic entering a given area.
The strength of this rule is that it only requires the
Analytics engine to monitor a person crossing one
tripwire, reducing possible points of failure. This rule
is ideal for areas where all of the pedestrian traffic is
meant to be counted.
In this example, any traffic travelling through this area is
considered to be entering or exiting the store.
General Tab
Name
Display Option
The rule name is used to easily identify the rule in the settings, live and alarms windows.
When building Analytics on an Enterprise level, consider Rule Naming conventions to
simplify searching and reporting on the data.
Select when the rule should be displayed in the live viewer. Show Rule will always display
the rule, Not Show Rule will never display the rule, Show Rule When Alarmed will only show
the rule while the alarm is triggered.
Database Insert
Frequency
The number of seconds between database entries. When a database insert is performed the
on-screen count restarts.
Description Enter a description for this Rule.
Check this box to allow data from this rule to sync to a central database. If this box is not
checked, this rule will not sync to a central database. This allows for rules that will be used
Allow Data from... in centralized reporting to sync to a central location, while rules that are not needed for
centralized reporting can stay local to the DVR and not use bandwidth / resources on the
central system.
