ETV System Server Software - User’s Guide Page 23
Video Search Results
After completing a search, the results are displayed in the Video Search Results pane as seen below. This pane
is expandable and collapsible if the POS/ATM Data search is enabled.
Visual Display
Tabular Display
Click this button or use the drop-down menu to switch between Visual and Tabular display options.
Visual display is a graphical representation of the search results. The visual footage chart shows the
period of time searched with footage recorded displayed as blocks of color representing the recording
mode:
Green for Constant, Blue for Motion or Red for Alarm.
Visual / Tabular
When the mouse is moved within the chart, a line is drawn indicating the point in time under the
cursor, which is displayed below the Video Search Results. Clicking within the chart will begin
playback of the selected camera at that time, clicking in a white section of the chart will begin
playback of the next available footage.
Tabular display is a table with the start and end dates and times of the available video footage.
Clicking on a table row will begin playback of the selected camera. The tabular display cannot show
gaps in video footage.
