ETV System Server Software - User’s Guide Page 119
16 Settings - Audio Tab
The Audio tab allows users to add Audio Channels and Audio Talk Devices to VIGIL Server and configure how
they are recorded.
Audio Recording Device Settings
Audio Recording Device settings are used to configure Audio Sources to be recorded on the DVR Server. These
can be IP Cameras, IP Audio Devices, Capture Card Inputs or DVR Sound Card Inputs.
Channel
Name
Device
Use settings
from camera
Enter a name for the audio channel. This
can be used to describe the location of the
audio source.
Select the type of audio device. IP Audio
from a supported IP Camera, Capture card
inputs or DVR audio inputs.
Enable to use settings from a currently
connected IP camera. Some cameras
require this option to be used or no audio
will record.
Type Select the type of IP camera.
Address The IP address of the IP camera.
Port The Port used on the IP camera.
URL The camera URL for certain camera types.
User Name /
Password
Timeout
Compression
The user name and password for the IP
camera.
The period of time in seconds before a
disconnection is determined to have
occurred.
The compression type for the Audio
channel. Select PCM for no compression,
or High for a compression ratio of 16 to 1.
Note: Capture card inputs and DVR audio inputs only require configuration of the Channel Name and
Compression. The form will change to reflect this when either of these types is selected in the Device Drop-
Down menu.
