ETV System Server Software - User’s Guide Page 115
Terminal Connection Settings
COM Port
When the POS/ATM connection type is set to Serial, select the COM port the Serial connection will
use from the Drop-Down list.
Port
When the POS/ATM connection type is set to IP Server, enter the Port that VIGIL Server will listen
on for the POS/ATM Data stream.
POS/ATM Alarm Settings
This setting becomes available once Priority Cameras are configured.
Enabled
Enable specific POS/ATM Data items to trigger an Alarm Event. This Alarm event will be recorded
to the POS Partition if data partitions have been enabled.
Dwell Time The time in seconds that the POS/ATM alarm event will record Video footage for.
Output Relay Select an Output Relay from the Drop-Down list to trigger when a POS/ATM Data Alarm occurs.
Trigger
Select whether the Relay will be triggered momentary, or latched on for the durations of the Dwell
Time.
Filter Settings...
Open the POS/ATM Alarm Filters window to configure POS/ATM events that will trigger POS/ATM Data Alarms.
No Sale Enable POS/ATM Alarms for all ‘No Sale’ items.
Void Enable POS/ATM Alarms for all ‘Void’ items.
Value
A POS/ATM Alarm will trigger for any item with the
value that is configured. Choose Greater than,
Less than or equal to from the Drop-Down box,
and set a value in the entry field.
Item / Codes
Tabs
Add or delete Specific Item names or Codes that
will trigger a POS/ATM Alarm. The text must be an
exact match for the POS/ATM data record including
spaces, but it is not case sensitive.
Filter Method
Select AND to meet all criteria listed before a
POS/ATM Alarm is triggered. Select OR for any
criteria to trigger a POS/ATM Alarm.
