Chapter 1 Brief Introduction
1.1 Description
Speed Dome is new products model which features built-in Auto focus camera module. Inner Pan/tilt
integrated with digital decoder which support line fault diagnosis, and 3D position function. Speed dome set
up the precision sensitive and stability motor gives camera no shake in any level speed.
Speed Dome is via digital control with precis simple drive system. The function is not only realize the
presets; horizontal scanning;frame scanning;following scanning, and panoramic scanning but also realize
the manual limit position;auto flip;privacy mask;and backlight compensation. The personal privacy is given
the best protection when the speed dome works on no blind spot panoramic monitoring.
IR Speed Dome support PELCO-D;PELCO-P,TA protocol ..etc, and it can match protocol
automaticly. To convenience to user, the speed dome capability with hardware dip address and software
address. User can config the System Information; Display; Camera Settings; Presets Settings; Mode
Settings; Alarm Settings; Auxiliary Switcher Settings ..etc via the Muti-language Menu.
1. Infrared Function
 Quickly cooling cast aluminum design.
 CCVE and PWM design, IR LED can work steady in long time.
 IDS (Intelligent Dimmer System), The IR brightness can be fixed by distance, zoom and brightness of
picture.
 Individual MCU infrared control system, The muti mode and remote upgrade system can be configured
 Multi-mode infrared settings, unique MCU IR control system,Remote upgrade system.
 10 grade IR power and illumination can be set.
 Perfect IR vision via internal switch between IR control and camera module optical filter .
 IP 66 Grade,TVS 4,000V lightning protection and voltage transient protection.
 3 Channel temperature control system, detect the camera and IR LED temperature.
2. System Function
 Integrate Structure Design.
 CGS (Cooling GAS System).
 IP 66 Grade,TVS 4,000V lightning protection and voltage transient protection.
 3 Channel temperature control system, detect the camera and IR LED temperature.
 Multi-Axis Design.
