1) Protocol Rule
Protocol SW1-1 SW1-2 SW1-3
Auto Match/PELCO-D OFF OFF OFF
TA OFF OFF ON
PELCO-P ON OFF OFF
Save …… …… ……
2) Baud Rate Rules
Baud Rate SW1-4 SW1-5
Auto Match/1200BPS OFF OFF
2400BPS ON OFF
4800BPS OFF ON
9600BPS ON ON
3) 120Ω ohmic resistance Configuration
SW1 is the 120Ω ohmic resistance of RS485. Please configure it as the 《Appendix 2 RS485 BUS
Connection》.
4) Communicated Address Configuration
SW2 configure the Speed Dome address. The speed dome address is binary system, No.8 is MSB,
No.2 is the LSB. PELCO-D/TA please refer as Appendix 5 . 2.5 Alarm Wire Diagram Speed Dome support 4 channel alarm output and 2 channel input; Following is the diagram. Port Name Description COM1 Alarm Output Channel , 1 Common Port NO1 Alarm NO Output Channel 1 COM2 Alarm Output Channel 2 Common Port NO2 Alarm NO Output Channel 2 GND Alarm Output GND IN 4 Alarm Input Channel 4 IN 3 Alarm Input Channel 3 IN 2 Alarm Input Channel 2 IN 1 Alarm Input Channel 1 GND Alarm Input GND Pages: 1 … 13 14 15 16 17 … 46 wrong Brand wrong Model non readable This manual is related to the following products: PPTZ-56-37R See also other documents in the category eLine Technology Camcorders: AN2 Series (6 pages) AN1 Series (6 pages) PPTZ (42 pages) DFB Quick Start (26 pages) DFB User Manual (41 pages) EDC User Manual (10 pages) EDC Quick Start (2 pages) EEOHT (1 page) EFB_EEFB User Manual (9 pages) EFB_EEFB Quick Start (2 pages) EPTZ-27IR User Manual (28 pages) EPTZ-27DN User Manual (26 pages) EVC-Z OSDmenu (3 pages) EVC User Manual (10 pages) EVC Quick Start (2 pages) EYS-SIP (3 pages) PRO3 Effio E (18 pages) PRO3 Effio P & S (20 pages) PVDC (1 page) VLVD-PIR (1 page) VLB-PIR (1 page) VL-PIR (16 pages) VDM_‐VDM‐IR Quick Start (2 pages) VDM_‐VDM‐IR User Manual (9 pages) Covert 3-Ring Binder Camera (3 pages) SIP-VD-R (38 pages) SIP-MVD-R (36 pages) SIP-B-R (36 pages) SIP-D (36 pages) SIP-ED-R (36 pages) SIP-FB (35 pages) Sitemap
2.5 Alarm Wire Diagram
Speed Dome support 4 channel alarm output and 2 channel input; Following is the diagram.
Port Name Description
COM1 Alarm Output Channel , 1 Common Port
NO1 Alarm NO Output Channel 1
COM2 Alarm Output Channel 2 Common Port
NO2 Alarm NO Output Channel 2
GND Alarm Output GND
IN 4 Alarm Input Channel 4
IN 3 Alarm Input Channel 3
IN 2 Alarm Input Channel 2
IN 1 Alarm Input Channel 1
GND Alarm Input GND
