eLineTechnology.com 21
5.1 Menu operation guide
Call preset point No.95 to open the menu via controller keyboard,DVR,client software.Please refer to
5.1.1.For example,If you want to open the camera menu.you could enter PTZ Housing mode according to
at front of panel with "PTZ Housing"button,then press "Video"button,Finally press No.keys "0 9 5" or press
No.keys "0 9 5" on the controller keyboard,then press "call" button.
Changed the cursor position via operate up,down,left,right.Please move the cursor to the menu you
needed,press " Aperture + (OPEN) " button or call preset point No.1 for SURE.( Represented with the
OPEN in this Manual),it was operate the menu.If the menu item have the sub-menu,please enter the
corresponding sub-menu;Press "IRIS-(CLOSE)" Button or call preset point 2 for give up and return
back(Represented with the CLOSE in the Manual),So it will give up to editing the menu items,When you
are in selecting menu mode,it will return back to previous menu until exit the menu.
In this GUI menu,When you modify the menu,it will press button for enter the modify
type.There are drop-down list,table,input method,Coordinate curve editing operation in modification of the
menu items.
List Operation: At most modify objects,using list box operation.When you press ,it will
pop-up the list of items you could modify.it can move to the options you need when operation upper and
lower,Choose the options you need,press button for confirmation modify.When an entry exists in
multiple sub-item,the left and right operation will be around you need to modify the subproject.
Table Operation: in the form selected state,press button enter cells selected state,Upper
and lower operation could selected the cell you modify.When the table can not fully display the data
items,the table will smart scroll.Press OPEN for pop-up the modify items.In the modify interface,press
for modify,press for cancel.
In selected cell state,it can bulk editing mode via TELE,WIDE operation,When it was bulk editing
mode,selected cells for anti-color display,upper and lower operation can be smart filled at same
time.The default that as copy way for filling.Selected the modify of items you need,press for
confirmation revise,press for cancel revise.When you need filling with increment or
decrement,when you in the second cell,left and right operate for second cell numerical,it is length
between the difference numerical of frist cell and second cell.
Coordinate curve operate : Selected coordinate curve,press button for enter spline
modification,it will show triangle guidepost above modification spot.Modify the spot numerical with left and
right operate.when it was adjusted,press button confirmation modification.
Text Input : When it was text type in selected modification items,the system will pop-up text input
keyboard.Upper,lower,left and right operate for selected the input data you need.Press button
confirmation items,press button for cancel.
