38
Power supply not sufficient
or Power cables too long
Replace
IR intelligent high-speed
dome out of control
Abnormal self-check
Power On again
Bad contact of control lines
Remove
The host operations have a
problem
Power up the host again
the load is too much ,the
distance is too far
Increase yards distributor
Focus out of control
Focus is in automatic mode
Set focus mode to manual
摄像机不能变倍
不支持的摄像机
更换
摄像机识别模式是手动模式
连续调用
49 号预置点和 17 号预
置点设置成自动识别摄像机模式
摄像机故障
更换摄像机
Appendix III The relationship between Wire and Distance
When the Wire diameter size is same and the 24VAC power loss below 10%,Recommended
Max.transmission distance.( For AC powered equipment,Max. Power loss is 10% is allowed.For
example,One deceive rated power is 80W,Installed 35 feet from the transformer <10M> distance,it will
need the Min.wire size is 0.80mm ).
Power W
Distance(m)
Wire Dia. mm
0.80
1.00
1.25
2.00
10 283(86)
451(137)
716(218)
1811(551)
20 141(42)
225(68)
358(109)
905(275)
30 94(28)
150(45)
238(72)
603(183)
40 70(21)
112(34)
179(54)
452(137)
50 56(17)
90(27)
143(43)
362(110)
60 47(14)
75(22)
119(36)
301(91)
70 40(12)
64(19)
102(31)
258(78)
80
35(10) 56(17) 89(27) 226(68)
90 31(9)
50(15)
79(24)
201(61)
100 28(8)
45(13)
71(21)
181(55)
110 25(7)
41(12)
65(19)
164(49)
120 23(7)
37(11)
59(17)
150(45)
