Figure 3 – Draw-Tite 50084 CUSTOM QUICK INSTALL BRACKETS User Manual
Page 4
©
2012 Cequent Performance Products, Inc.
Rev. D
50084N
9/18/12
4
DIMENSIONS SPECIFIC FOR RAIL KIT 30035 OR 58058
Figure 3
FRONT OF VEHICLE
F
RO
NT
O
F
B
E
D
B
ACK
O
F
B
E
D
27 9/16”
DRILL AND BOLT LOCATIONS
HEX HEAD BOLT
HEX HEAD BOLT
C OF HITCH
L
HITCH SUPPORT / SLIDER / GOOSE
(HITCH SUPPORT NOT SHOWN)
BUMPER / HITCH BRACKET
C OF AXLE
L
APPROX. 1 3/4”
APPROX. 1 3/4”
APPROX. 1 3/4”
APPROX. 1 3/4”
MOUNTING RAIL
