Tool ConfiguraTions
Climax Portable Machining & Welding Systems Web site: climaxportable.com
Worldwide Phone:
1.503.538.2185 N. America Toll-Free: 1.800.333.8311 Fax: 1.503.538.7600 E-mail: [email protected]
page 3
Configure your BB8100 in eight easy steps.
To configure your BB8100 Boring Machine:
1 Select a Base Unit
2 Select an Axial Feed Assembly
3 Select Bearing Assemblies
4 Select a Boring Bar
5 Select a Hydraulic Motor Assembly
6 Select a Tool Head Assembly
7 Select a Boring/Facing Arm Assembly
8 Select a Shipping Container
To configure the boring machine you require, simply select
the option you need in each step, then contact your Climax
representative.
1 Base Unit
Rotational drive unit, tool carrier assembly,
tool kit, and instruction manual.
Base unit, 20:1 gear ratio 54453
Base unit, 10:1 gear ratio 54454
2 Axial Feed Assembly
Mechanical axial feed assembly 23393
Electrical axial feed assembly, 120V 43734
Electrical axial feed assembly, 230V 40724
3 Bearing Assemblies
End mount self-aligning bearing assy w/ spider 23550
End mount self-aligning bearing assy, no spider 25074
ID mount non self-aligning bearing assembly 18572
diameter of 23 - 27.5 inches (584.2 - 698.5 mm)
ID mount non self-aligning bearing assembly 18573
diameter of 23 - 35 inches (584.2 - 889.0 mm)
ID mount non self-aligning bearing assembly 18574
diameter of 23 - 49.5 inches (584.2 - 1257.3 mm)
ID mount non self-aligning bearing assembly 18575
diameter of 23 - 63.5 inches (584.2 - 1612.9 mm)
ID mount non self-aligning bearing assembly 18576
diameter of 23 - 77 inches (584.2 - 1955.8 mm)
Non self-aligning bearing assembly, no spider 18533
* Multiple units may be ordered.
4 Boring Bar (8 inch (203.2 mm) diameter)
Boring bar assembly, 8 feet (243.8 cm) 34305
Boring bar assembly, 10 feet (304.8 cm) 34306
Boring bar assembly, 12 feet (365.8 cm) 34307
Boring bar assembly, 14 feet (426.7 cm) 34308
Boring bar assembly, 16 feet (487.7 cm) 34309
Boring bar assembly, 18 feet (548.6 cm) 34310
Boring bar assembly, 20 feet (609.6 cm) 34311
Gun-drilled bars with optical targets:
Boring bar assembly, with optics, 8 feet (243.8 cm) 17602
Boring bar assembly, with optics, 10 feet (304.8 cm) 17603
Boring bar assembly, with optics, 12 feet (365.8 cm) 17604
Boring bar assembly, with optics, 14 feet (426.7 cm) 17605
Boring bar assembly, with optics, 16 feet (487.7 cm) 17606
Boring bar assembly, with optics, 18 feet (548.6 cm) 17607
Boring bar assembly, with optics, 20 feet (609.6 cm) 17608
* Multiple units may be ordered.
5 Hydraulic Motor Assembly
Hydraulic motor assembly, 7.3 CIR (120 cm3/rev) 43455
44 bar rpm @ 15 gpm**
Hydraulic motor assembly, 8.9 CIR (146 cm3/rev) 43456\
36 bar rpm @ 15 gpm**
Hydraulic motor assembly, 11.3 CIR (185 cm3/rev) 43457
29 bar rpm @ 15 gpm**
Hydraulic motor assembly, 14.1 CIR (231 cm3/rev) 43458
22 bar rpm @ 15 gpm**
Hydraulic motor assembly, 17.9 CIR (293 cm3/rev) 43459
18 bar rpm @ 15 gpm**
* Multiple units may be ordered.
** Theoretical, calculated values shown
6 Tool Head Assembly
Boring head set, 18.1 - 26.1 inches (459.7 - 662.9 mm) 57258
Boring head set, 18.1 - 40.1 inches (459.7 - 1018.5 mm) 55622
Boring head set, 18.1 - 80.1 inches (459.7 - 2034.5 mm) 55623
7 Boring/Facing Arm Assembly
Mechanical facing head assy, 5 inch (127.0 mm) 21115
Mechanical facing head assy, 8 inch (203.2 mm) 38654
Mechanical facing head assy, 12 inch (304.8 mm) 22359
Boring/facing arm assembly, 26 inch (660.4 mm) 54401
Boring/facing arm assembly, 34 inch (863.6 mm) 54402
Boring/facing arm assembly, 53 inch (1346.2 mm) 54403
8 Shipping Container
Plywood hinged crate, 39 x 58 x 31inches 42955
(990.6 x 1473.2 x 787.4 mm)
Metal shipping container, 39 x 58 x 31inches 54368
(990.6 x 1473.2 x 787.4 mm)
* Machine components only.
Bars and bearings available in wood only.
aPPlication
The BB8100 Portable Boring Machine
is widely used by these industries:
Mining
• Drag line repair
Shipbuilding & Ship Repair
• Rudder pin and stern tube boring
• Diesel engine crankshaft and cylinder bore repair
• Turbine housing repair
Industrial
• Stamping press bearing seat repair
• Line boring gear boxes
• Power Generation
• Pump repair
• Turbine repair
