Operational dimensions, Dimensions in inch (mm) – Climax LM6200 LINEAR/GANTRY MILL User Manual
Page 6
Climax Portable Machining & Welding Systems Web site: climaxportable.com
Worldwide Phone:
1.503.538.2185 N. America Toll-Free: 1.800.333.8311 Fax: 1.503.538.7600 E-mail: [email protected]
page 6
OPERATIONAL DIMENSIONS
Milling Area Dimensions - LINEAR MILLING
Milling Area Dimensions - GANTRY MILLING
Bed Length
X Travel +23" (584.2 mm)
3.5" (88.9 mm)
Typical
Y Travel + 11" (279.4 mm)
Y Travel
Max Separation
Y Travel - 8" (203.2 mm)
Dimensions in Inch (mm)
