Appendices, Appendix a: specifications – MoTeC MDD User Manual
Page 36
34 Appendices
Appendices
Appendix A: Specifications
Electrical
Operating Voltage Range: 6.5V to 15V
Reverse polarity protected
Operating Current:
at normal brightness: 85mA Typical (8V to 14V)
at full brightness: 150mA Typical at 14V
Environmental
Operating Temperature Range: -10
°C to 70°C Internal (65°C Ambient Typical)
Weight: 120grams (0.26 lb) Approx.
Dimensions (W x H x D): 85.8 x 59.5 x 21.9 mm (3.38 x 2.34 x 0.86 in)
Communications
CAN Interface
1 Mbit/sec
Serial
9600 baud, Logic Level.
