MoTeC MDD User Manual
Page 30
28 M4/48
Operation
Fuel Injector Duty
Cycle (%)
Fuel Cut level (%)
Ignition Cut level (%)
Fuel Actual Pulse
Width (mS)
Fuel Used
Aux Output 1 Duty
Cycle (%)
Aux Output 2 Duty
Cycle (%)
Aux Output 3 Duty
Cycle (%)
Aux Output 4 Duty
Cycle (%)
A maximum of 14 active M4/M48
diagnostics can be displayed at any
time.
A maximum of 14 active M4/M48 status
flags can be displayed at any time.
BR2 comms status (active or inactive)
Units conversion status, On (°F) or Off
(°C)
Firmware version and date
