Page 18
16 M800
Operation
When a particular layout has been displayed for at least 60 seconds (without a
button press) the current layout selection is stored in the MDD. When the MDD
is next powered up it will then display this layout.
User Mode Layouts for M800
The M800 user mode layout displays four fixed parameters (Gear, RPM,
Engine Temperature and Ground Speed) in the top section of the screen. The
bottom line of the screen can display one of seven different layouts (selected
with the button), or a lap time override if a BR2 is present and lap beacon has
been passed (see the BR2 Operation section).
The seven user mode layouts are shown below in the order they occur:
Lap Time
This layout is only shown if a BR2 is
present
Fastest Lap Time
This layout is only shown if a BR2 is
present
