Tuning Mode Layouts for M4/M48
The M4/M48 tuning mode has seven different screen layouts, shown below in
the order they occur:
RPM
Throttle Position
Efficiency Point
Lambda
Engine Temperature (°C)
Air Temperature (°C)
Auxiliary Voltage
Auxiliary Temperature
RPM
Throttle Position (%)
Manifold Pressure
(kPa)
Air Temperature
(°C)
Lambda
Lambda Short Term
Trim
Engine Temperature
(°C)
Digital Input 1 speed
Battery Voltage
