8
PULSE FUNCTIONS
Single One pulse at each selected period up to 50 MHz repetition rate
Double
One pair of pulses at each period up to 25 MHz repetition rate. Both pulses
have the same selected width; the position of the second pulse set by the
delay control.
TRANSITION TIMES
Range
<6 ns to 100 ms variable. Leading and trailing edges settable separately
and limited to 20:1 ratio between settings into one of the following ranges:
5ns-100 ns; 50 ns-1.0 us; 500 ns-10 us; 5.0 us-100 us; 50 us-1.0 ms; 500
us-10 ms, 5 ms – 100 ms
Resolution 3 digits limited to 10 ps
Accuracy
±(5% of setting +2ns)
Linearity
<5% deviation from a straight line between 10% and 90% points, for
transitions > 50 ns
INTERNAL TRIGGER
Range 100 ns to 100 s
Resolution 4 digits limited to 100 ns
Accuracy
± 0.01%
INPUT AND OUTPUT
TRIGGER
INPUT Sensitivity 200 mVp-p minimum
Minimum Width 10 ns
Maximum Rate 50 MHz
Input Impedance 10 k
Ω
Input Protection +15V DC plus peak AC
Range Selectable from -10 V to +10 V
Resolution 3 digits limited to 10 mV
Slope Selection Positive or Negative
SYNC OUTPUT A TTL level pulse at the programmed period. Output impedance is 50
Ω,
protected against short circuit and up to
±15 V accidental input. The high
level is >2 V into 50 ohms and with 3.5 ns typical transition times.
GPIB PROGRAMMING
Interface GPIB and RS-232, IEEE-488.2 and SCPI compatible
GPIB Function Codes SH1, AH1, T6, L4, SR1, RL1, PP0, DC1,DT1, C0, E2
GENERAL
Memory
Non volatile, stores up to 99 complete panel settings. Last user setup also
retained at power down
Power Requirements 100-240 V,
±10%, 48-66 Hz, 50 VA maximum
Dimensions WxHxD 8.4 x 11.8 x 3.5 inches (213 x 300 x 88 mm)
Net Weight Approx. 3 kg
EMC Conforms to EN55011 class B for radiated and conducted emissions
Electrical Discharge Immunity Conforms to EN55082
Safety Specifications Conforms to EN61010, CE Approved
Operating Temperature 32 °F to 122 ° F (0 °C to 50 °C)
Storage Temperature -4 ° F to 140 °F (-20 °C to 60 °C)
Humidity 90% RH at 32 °F to 86 °F (0 °C to 30 °C)
