7
Specifications
NOTE
Specifications listed in manual are applicable after a powered 30 minute warm-up into a 50
Ω load
All timing characteristics are measured at 50% of amplitude with fastest edge
Specifications are verified according to the performance check procedures.
Specifications not verified in the manual are either explanatory notes or general performance characteristics only.
Specifications and information is subject to change without notice. For the most current and correct data please
visit
www.bkprecision.com
MODELS
4033 4034
CHANNELS 1 2
FREQUENCY 0.1 Hz to 50 MHz
TIMING CHARACTERISTICS
PERIOD
Range (single pulse) 20 ns to 10 s (50 MHz to 0.1 Hz repetition rate)
Range (double
pulse) 40 ns to 10 s (25 MHz to 0.1 Hz repetition rate)
Resolution Up to 6 digits, limited to 10 ps
Accuracy
± 0.01 %
Jitter < 0.01 % of setting +20 ps on Period, Width and Delay
WIDTH Range 10 ns to (Period – 10 ns)
Resolution Up to 6 digits, limited to 100 ps
Accuracy
±(0.5% of setting +500 ps)
Double Pulse
±(0.5% of setting +3 ns) for the second pulse
DELAY Range 0ns to (Period – Width – 10 ns)
Resolution Up to 6 digits, limited to 100 ps
Accuracy
±(0.5% of setting +500 ps)
DUTY
CYCLE Range 1 to 99%
Resolution 3 digits (0.1%)
Accuracy Limited by width and pulse accuracy
OUTPUT CHARACTERISTICS
AMPLITUDE
High Level
Range -9.90 V to +10 V into 50 ohms load (-19.80 V to +20 V into open circuit)
Low Level
Range -10 V to +9.90 V into 50 ohms load (-20 V to +19.80 V into open circuit)
Amplitude Range 0.1V to 10V p-p into 50 ohms load (20 Vp-p max into open circuit)
Resolution
3 digits limited to 10 mV
Accuracy ± 1% of setting ± 10 mV into 50 ohms
Aberrations <5% + 20 mV into 50 ohms load, for pulse levels between
±5 V
Output
Resistance 50 ohms
Offset Accuracy
± 1% ± 25 mV
OPERATING MODES
Continuous Output continuous at programmed period rate
Triggered
Output quiescent until triggered by an internal, external, GPIB or manual
trigger, then generates one cycle at programmed period rate
Gated
Same as triggered mode except pulses are output for the duration of the
gated signal. The last cycle started is completed
Burst
Same as triggered mode for programmed number of cycles from 2 to
999,999 as set by the N-BURST function
External Width Trigger duration and rate sets pulse width and repetition
