Version 09.00, December 2008 R&S ® FSL Spectrum Analyzer 9
Level measurement uncertainty
95 % confidence level, +20 °C to +30 °C,
S/N > 16 dB, 0 dB to –50 dB from reference level
10 MHz < f ≤ 3 GHz <0.5 dB
3 GHz < f ≤ 6 GHz <0.8 dB
6 GHz < f ≤ 18 GHz <1.2 dB
Absolute uncertainty at 65.83 MHz <0.3 dB
9 kHz ≤ f < 30 kHz nominal 1.5 dB
30 kHz ≤ f ≤ 3 GHz <0.5 dB, typ. 0.3 dB
3 GHz < f ≤ 6 GHz <0.8 dB, typ. 0.3 dB
6 GHz < f ≤ 18 GHz <1.2 dB, typ. 0.6 dB
Frequency response (+20 °C to +30 °C)
f > 18 GHz nominal 2 dB
Attenuator uncertainty <0.3 dB
Uncertainty of reference level setting nominal <0.1 dB
Display nonlinearity
Logarithmic level display
S/N > 16 dB
0 dB to –50 dB
<0.2 dB
Bandwidth switching uncertainty reference: RBW = 10 kHz nominal <0.1 dB
Trigger functions
Trigger
Trigger source
free run, video, external, IF power
External trigger level TTL level
I/Q data
LAN Interface
R&S ® FSL-B10 LAN or GPIB
Memory length max. 512 ksample I and Q
Sample rate 10 kHz to 65.8 MHz
Signal bandwidth sample rate 65.8 MHz nominal 28 MHz
