Pna series simplified test set block diagram – Atec Agilent-E8364A User Manual
Page 25
PNA Series simplified test set block diagram
Standard power range
Extended configuration, source access, receiver (Option 014)
25
Source
Switch
Reference
receiver
Reference
receiver
Measurement
receivers
Port 1
Port 2
A
B
R1
R2
Source
Switch
Reference
receiver
Reference
receiver
Measurement
receivers
Port 1
Port 2
A
B
R1
R2
