Operation, cont’d

VSC 200/200D/300/300D Operation

3-6

3.

Select the filters:

a.

Press and release the Menu button until the filter controls menu appears.

b.

Press the Next button.

c.

Press the Up or Down cursor buttons to select the horizontal filter that
provides the most improvement to the image detail. You can use an
alternating pixel pattern to perform this adjustment.

d.

Press the Next button.

e.

Press the Up or Down cursor buttons to select the vertical filter that
provides the greatest reduction of flicker while maintaining image
sharpness. You can use an image pattern of horizontal lines, such as a
crosshatch, to perform this adjustment.

Figure 19 — Selecting the filters

If the filters are set before the image size is adjusted, you must set the filters
again after adjusting the image size.

4.

Select the encoder filter:

a.

Press and release the Menu button until the configuration controls menu
appears.

b.

Press and release the Next button until the encoder filter screen appears.

c.

Press the Left or Right cursor buttons to select the encoder filter that
provides the sharpest overall image. You can use a text pattern to
perform this adjustment.

Figure 20 — Selecting the encoder filter

Setting Up Genlock and Vertical Interval Switching

A genlock (black burst generator) device can be connected to the scan converter to
synchronize it with other system components for seamless vertical interval
switching between sources.

Vertical interval switching setup

For vertical interval switching (to allow clean switching between signals from
several devices during the vertical blanking period of each signal), a composite
sync signal can be applied at the Genlock In connector, and also passed to another
device via the Genlock Out connector.

FILTER

CONTROLS

ZOOM/SIZE/PAN

CONTROLS

Menu button

CONFIGURATION

CONTROLS

Menu button

OUTPUT RES.

xxxxxxxx

Next button

OUTPUT

SVID YUV

Next button

STANDARD

PAL

Next button

Menu button

ENCODER FILTER

STD HI

Next button

FILTER

CONTROLS

ZOOM/SIZE/PAN

CONTROLS

Menu button

Menu button

VERTICAL FILTER

0 1 <2> 3 4

HORZ. FILTER

1 <2> 3 4

Next button

Next button
