Installation, cont’d
VSC 200/200D/300/300D Installation 2-4
14 RGB/R-Y, Y, B-Y LED — Lights to indicate that the RGB or component video
output is active.
Component video (R-Y, Y, B-Y) is referred to as YUV in the front panel LCD
menus.
15 Sync selection switch — Allows you to choose how the sync output signals
for RGsB/RGBS/RGBHV are routed:
H — If the switch is set to H, the scan converter outputs separate horizontal
and vertical sync signals; only horizontal sync is routed through the
H/HV output connector.
HV — If the switch is set to H/V, the scan converter outputs a composite sync
signal (H and V combined) on the H/HV output connector.
SOG — If the switch is set to SOG (sync on green), the scan converter outputs
a composite sync signal on the green video signal via the G/Y output
connector.
16 V output connector — Vertical sync output (RGBHV).
17 15-pin VGA output connector (VSC 300/300D only) — Scaled VGA output.
18 VGA LED (VSC 300/300D only) — Lights to indicate that the VGA output is
active.
19 Genlock input connector — Genlock reference signal input.
20 Genlock output connector — Passes the genlock reference signal to the next
device. If the signal is not passed to another device, connect a 75-ohm
termination adapter.
21 RS-232 connector — 9-pin D female connector that allows you to attach a
computer or controlling device for remote control of the scan converter.
Installation Overview
To install the scan converter, follow these general steps:
1 If desired, mount the scan converter in a rack (see “Mounting the scan
converter” on page 2-5). Otherwise, install the rubber feet (see “Tabletop/
desktop placement” on page 2-6).
2 Turn off power to the input and output devices, and unplug the power cables
from them.
3 Attach the input device and the output device to the scan converter. See
“Cabling” on page 2-6.
4 Set the configuration switches.
5 Plug the scan converter, input device, and output device into a grounded AC
source.
6 Turn on the input and output devices.
7 Use the LCD menu screens to configure the scan converter. See “Front Panel
Operation”, page 3-2.
8 The image from the input device should appear on the output device. If it
does not, double check steps 3 and 4 and make adjustments as needed. See
chapter 5 for additional assistance.
9 Optimize the image for your display environment. See “Optimizing the
image” on page 3-5.
