Ear panel, Dip switch 7 – Extron Electronics RGB 203 Rxi User Guide User Manual
Page 15
5.
Monitor follows
This switch controls the input assigned to the local monitor output and ID bit
termination.
On — The local monitor connector follows the input selection and ID bits 4 and 11
are tied to ground.
Off — The local monitor output connector is locked to input 1 and ID bits 4 and 11
are unterminated.
6.
Mono audio left
On — Mono audio is output in the left channel only.
Off — Output is normal stereo audio.
7.
Auto switching
On — The interface automatically switches to the highest numbered input with sync
present.
Off — The input must be switched manually.
NOTE: Auto switch works for RGBHV and RGBS inputs only. Auto switch does
not work for RGsB input.
8.
Backlight illumination
This switch controls illumination of the LCD backlight.
On — The LCD backlight is off, except for three seconds at power-up.
Off — The LCD backlight is on while a signal is present at the selected input.
