MLC 104 Series MediaLink Controllers • Software Setup

Software Setup, cont’d

3-22

MLC 104 Series MediaLink Controllers • Software Setup

3-23

Uploadng a configuraton

The process of uploading your project is essential to successfully

configuring the MLC 104 and creating a GlobalViewer Web page

for the MLC 104 IP. You can upload the project to one MLC at a

time or several at once.

N

You can configure devices offline, but the device must be

connected to the network for a successful upload.

The Upload Manager appears only after a build has been

successfully performed on at least one device. If errors occur

during the build of any devices, a dialog box appears listing the

errors.

The Upload Manager window before file upload

To begin the upload, do the following:
1

.

Click Begin. The Upload Manger monitors the progress of

the download.

2

.

Click Close.
The configuration should now be successfully uploaded to

the appropriate product(s).

Accessng GlobalVewer

®

After uploading a configuration file to a MLC 104 IP controller,

there are two ways to access the GlobalViewer Web page:

From the Upload Manager window, click the
Test GV System

button.

Right-click the MLC 104 IP controller icon in the IP Link

tree and select Open GlobalViewer

®

Webpage

.

GlobalViewer main page
